LAVA 4260 Thermal Flexo Processor
Press Ready Plates in Under 60 Minutes
- Plate SizeThe LAVA 4260 can process plates up to 42 inches(1,066 mm) wideand 61 inches (1,549 mm) long
- Length76.57 in (1945 mm)
- Width75.98 in (1930 mm)
- Height53.54 in (1360 mm)
- Power400V, 3P w/N, 16A 230V, 3P, 27A
- Plate SizeThe LAVA 4260 can process plates up to 42 inches(1,066 mm) wideand 61 inches (1,549 mm) long
- Length76.57 in (1945 mm)
- Width75.98 in (1930 mm)
- Height53.54 in (1360 mm)
- Power400V, 3P w/N, 16A 230V, 3P, 27A
LAVA 4260 Thermal Flexo Processor Overview
Press-ready Plates in under 60 Minutes
Benefits
PLATES IN UNDER
60 MINUTES
LAVA Thermal platemaking improves productivity and workflow, generating press-ready plates in less than an hour. Additionally, LAVA Thermal Plate Processing eliminates solvents and VOCs from the
platemaking process, resulting in a more environmentally friendly process. The LAVA Plate Processing System is ideal for narrow web, mid-web, and wide-web applications. The advanced design of the LAVA system incorporates an internal filter system for reduced footprint, an automated lift lid, and LED illumination.
Elimination of solventsfrom the platemaking process.
Smaller equipment footprint than solvent systems.
Vapor management system.
User friendly touch screen and software.
Durable and rigid sub-frame for consistent processing month to month, year to year.
Remote access and Diagnostics.
Let’s optimize your printing process!
Contact us for innovative solutions and expert support.
Specifications
- Plate SizeThe LAVA 4260 can process plates up to 42 inches(1,066 mm) wideand 61 inches (1,549 mm) long
- Length76.57 in (1945 mm)
- Width75.98 in (1930 mm)
- Height53.54 in (1360 mm)
- Power400V, 3P w/N, 16A 230V, 3P, 27A
- AirNo Less than 6 bar (87 PSI) / Consumption: avg. 70 L/Hr (6mm Hose)
- Ventilation382.5 CFM (650 m /hr) Width A flexible 100 mm diameter hose to connect with your factory exhaust system.
Brochure LAVA 4260 EN
