nyloflex® MVP 272D
Versatile in print & processing
Main specifications
- Color of raw platepurple
- Total thickness (mm)2.72
- Plate hardness (Shore A)52
- Recommended Relief depth (mm)0.9 – 1.2
- Tonal range (%)1-98
Main specifications
- Color of raw platepurple
- Total thickness (mm)2.72
- Plate hardness (Shore A)52
- Recommended Relief depth (mm)0.9 – 1.2
- Tonal range (%)1-98
nyloflex® MVP 272D Overview
Benefits
SUPERIOR PRINT QUALITY AND EFFICIENCY
- Developed for the perfect balance between excellent ink lay-down and highlight performance.
- Minimize waste by combining flexible packaging and label jobs on one plate.
- Longer durability thanks to less plate swelling on press.
Suitable equipment
nyloflex® MVP Digital plates may be exposed using any nyloflex® exposure system and all similar devices and can be used with all laser systems suitable for imaging flexo printing plates. nyloflex® MVP Digital plates can be processed in either solvent or LAVA® thermal processing systems.
Printing inks
Suitable for all UV, water based and solvent based printing inks4 (ethyl acetate content preferably below 15%, ketone content preferably below 5%).
Processing Information
A detailed description of the imaging, exposure and finishing steps, as well as detailed information about handling and storing, can be found in the nyloflex® User Guide.
Certification
XSYS Photopolymer Products are manufacturing and distributed from Morristown, TN Production site, which is certified according to international standards for quality management (DIN EN ISO 9001:2015), and environmental management (DIN EN ISO14001:2015).
Get in touch
Let’s optimize your printing process!
Contact us for innovative solutions and expert support.
Specifications
The main specifications of the nyloflex® MVP 272D
- Color of raw platepurple
- Total thickness (mm)2.72
- Plate hardness (Shore A)52
- Recommended Relief depth (mm)0.9 – 1.2
- Tonal range (%)1-98
- at screen ruling (L/cm)80
- Fine line width (down to μm)100
- Isolated dot diameter (down to μm)175
- Back exposure (s)130 - 180
- Main exposure (min)10 - 12
- Post exposure UV-A (min)5
- Light finishing UV-C(min)34-8
